CMS-2010GF, L2+ Switch

L2+ Managed Fiber Switch – 20 x 1G/2.5G/10Gbps SFP+ Slots

The CMS-2010GF is a Layer 2+ managed fiber switch featuring 20 SFP/SFP+ ports supporting 1GbE, 2.5GbE, and 10GbE fiber or copper transceiver modules. With a 400Gbps switching capacity, 32K MAC address table, and 10KB jumbo frame support, it provides a high-performance switching platform for connecting 1G, 2.5G, and 10G network endpoints, while supporting aggregation and backbone links within enterprise and industrial networks.

Advanced Layer 2+ features include VLAN, Q-in-Q, MSTP/RSTP, ERPS, LACP, IGMP/MLD Snooping, multicast control, and QoS with eight priority queues per port. Security functions include IEEE 802.1X, RADIUS, TACACS+, ACL, DHCP Snooping, IP Source Guard, and Dynamic ARP Protection. Management is supported through Web GUI, CLI, SNMP, SSH, Telnet, LLDP, IPv4/IPv6, and dual firmware images. The 1U rack-mount switch is suitable for enterprise, industrial Ethernet, surveillance, data centre edge, and AV-over-IP network deployments requiring flexible 1G, 2.5G, and 10G connectivity.

Category: L2+ Managed Switches
SKU: CMS-2010GF

Contact Us Download to PDF

Overview

Product Features

Downloads

INTRODUCTION

The DSGio CMS-2010GF is a Layer 2+ managed fiber switch featuring 20 SFP/SFP+ ports supporting 1GbE, 2.5GbE, and 10GbE fiber or copper transceiver modules. With a 400Gbps switching capacity, 32K MAC address table, and 10KB jumbo frame support, it provides a high-performance switching platform for connecting 1G, 2.5G, and 10G network endpoints, while supporting aggregation and backbone links within enterprise and industrial networks.

The platform supports comprehensive Layer 2 networking features, including IEEE 802.1Q VLAN, Q-in-Q, Voice VLAN, MSTP/RSTP/STP, LACP link aggregation, and Ethernet Ring Protection Switching (ERPS). Multicast traffic management is supported through IGMP Snooping v1/v2/v3, MLD Snooping, IGMP Querier, IGMP Proxy, and MVR.

Quality of Service (QoS) functions include 8 hardware priority queues per port, IEEE 802.1p, DSCP classification, traffic scheduling, and ingress/egress rate limiting. Security features include IEEE 802.1X authentication, RADIUS, TACACS+, ACL, IP Source Guard, DHCP Snooping, Dynamic ARP Protection, Port Security, BPDU Guard, and management access filtering.

Management interfaces include Web GUI, CLI, SNMP v1/v2c/v3, Telnet, SSH v2, RMON, LLDP, NTP, and IPv6 configuration support. The switch also supports dual firmware images, configuration backup and restore, firmware upgrades via HTTP, and system event logging.

Housed in a 1U 19-inch rack-mountable metal enclosure, the CMS-2010GF operates from a universal 100–240VAC power source with a maximum power consumption of around 40W. An optional IEEE 1588v2 Precision Time Protocol (PTP) feature is available for time-synchronized network applications.

SPECIFICATIONS

Interface
1G/2.5G/10Gbps SFP+ Slot		20
RJ45 Console Port for CLI Management		1
System Performance
Packet Buffer		32Mb
NAND Flash Memory		2Gb
NOR Flash Memory		256Mb
SDRAM Memory (DDR3)		16Gb
MAC Address Table Size		32K
Jumbo Frame		10K
Switching Capacity		400Gbps
L2 Features
Auto-Negotiation		●
Auto MDI/MDI-X		●
Flow Control (Duplex)	802.3x (Full)	●
	Back-Pressure (Half)	●
Spanning Tree	IEEE 802.1D (STP)	●
	IEEE 802.1w (RSTP)	●
	IEEE 802.1s (MSTP)	●
VLAN	VLAN Group	4096
	Tagged Based	●
	Port-Based	●
	Q-in-Q	●
	Voice VLAN	Voice VLAN with OUI
	MAC-based / Protocol-based / IP Subnet-based VLAN	●
Link Aggregation	IEEE 802.3ad with LACP	●
	Static Trunk	●
	Max. Static Aggregation Group	10
	Max. Port per Static Agg. Group	16
IGMP Snooping	IGMP Snooping v1/v2/v3	Supports 1024 IGMP Groups
	IGMP Static Multicast Addresses	Supports 1024 Static Multicast Addresses
	IPv6 MLD Snooping	Supports 1024 MLD Groups
	MLD Static Multicast Addresses	Supports 1024 Static Multicast Addresses
	Querier, Immediate Leave	●
Storm Control (Broadcast / Multicast / Unknown Unicast)		●
Loop Protection		●
QoS Features
Number of Priority Queue		8 Queues/Port
Rate Limiting	Ingress	Yes, 1 KBps/1pps
	Egress	Yes, 1 KBps/1pps
DiffServ (RFC2474 Remarking)		●
Scheduling (WRR, Strict, Hybrid)		●
CoS	IEEE 802.1p	●
	IP ToS Precedence, IP DSCP	●
Security
Management System User Name / Password Protection		●
User Privilege		Set User Privilege up to 15 Level
Port Security (MAC-based)		●
IEEE 802.1x Port-based Access Control		●
ACL (L2/L3/L4)		●
IP Source Guard		●
RADIUS (Authentication, Authorisation, Accounting)		●
TACACS+		●
HTTP & SSL (Secure Web)		●
SSH v2.0 (Secured Telnet Session)		●
MAC/IP Filter		●
DHCP Snooping (DHCP Protection)		●
Port Isolation		●
BPDU Guard		●
STP Root Guard / Edge Safe Guard / Restricted Role		●
Dynamic ARP Protection		●
Management
Command Line Interface (CLI)		●
Web Based Management		●
Telnet		●
Access Management Filtering		SNMP/Web/SSH/Telnet
Firmware Upgrade via HTTP		●
Dual Firmware Images		●
Configuration Download / Upload		●
SNMP (v1/v2c/v3)		●
RMON (1, 2, 3 & 9 Groups)		●
DHCP (Server / Client / Relay / Option 82 / Snooping)		●
System Event / Error Log		●
TFTP (Trivial File Transfer Protocol)		●
NTP / LLDP		●
IPv6 Configuration		●
Port Mirroring		●
Physical Characteristics
Dimension (W x H x D)		440 x 44 x 220 mm
Reset Button		1
LED Indicator		Power, Link/Act.
Cooling		Fan Cooling
Enclosure		Metal
Installation		Rack Mount
Weight		2.8 Kg
System Power Requirements
System Power Input		100-240V~
System Power Consumption		~40W
Environment Limits
Operating Temperature		0 ~ 50°C
Storage Temperature		-20 ~ 80°C
Operating Humidity		10 ~ 90% RH (Non-condensing)
Storage Humidity		10 ~ 90% RH (Non-condensing)
Certifications and Protection
ESD		DC Contact 4KV, Air 8KV
Surge		AC Line to Line 1KV, Line to Ground 2KV
Certifications		CE, FCC, UKCA Class A
Standard
IEEE 802.3z – 1000Base-SX/LX		●
2.5G SFP 2.5GBase-X		●
IEEE 802.3ae – 10GBase SFP+		●
IEEE 802.3ab – 1000Base-T SFP		●
IEEE 802.3bz – 2.5GBase-T SFP		●
IEEE 802.3an – 10GBase-T SFP+		●
IEEE 802.3az – Energy Efficient Ethernet (EEE)		●
IEEE 802.3x – Flow Control		●
IEEE 802.3ad – Link Aggregation Control Protocol (LACP)		●
IEEE 802.1Q – VLAN Tagging		●
IEEE 802.1v – Protocol-Based VLAN		●
IEEE 802.1p – Class of Service (CoS)		●
IEEE 802.1D – Spanning Tree Protocol (STP)		●
IEEE 802.1w – Rapid Spanning Tree Protocol (RSTP)		●
IEEE 802.1s – Multiple Spanning Tree Protocol (MSTP)		●
IEEE 802.1AB – Link Layer Discovery Protocol (LLDP)		●
IEEE 802.1X – Port-Based Network Access Control		●
ITU-T G.8032/Y.1344 – Ethernet Ring Protection Switching (ERPS)		●
IEEE 1588v2 - Precision Time Protocol (PTP)		(OPTIONAL) Note: The standard firmware does not support IEEE 1588v2 (PTP). A dedicated firmware version is required for PTP support. Please contact DSGio Sales for quotation.
