USB 3.2 Gen 1, 5Gbps, USB-C Host Port, RS-232, FSYNC, PoC, 100m
(2 x USB-A and 2 x USB-C on RX)
The DSG-USB-EU301 supports USB 3.2 Gen 1 connectivity with data transfer rates up to 5Gbps and extends signals up to a distance of 100m (328ft) over a single CAT6a cable. It is fully backward compatible with USB 2.0 and 1.1, and features hardware acceleration for both isochronous and bulk data transfers.
The Transmitter (TX) features one USB Type-C host port, one FSYNC GPIO input and one RS-232 pass-through. The Receiver (RX) provides two USB Type-A device ports (1x 5V@1A and 1x 5V@1.5A), two USB Type-C device ports (1x 5V@1A and 1x 5V@1.5A), one FSYNC GPIO output, and one RS-232 pass-through.
Bi-directional 24V Power over Cable (PoC) is supported.
